Pcs 3G-OTH-227443 — Technical Specifications

Name: Pcs 3G-OTH-227443 PCS Step Ejector Pin: Step Pin, Tool Steel, 3/32 in Nom. Dia., 8 in Overall Lg, 1/8 in Shoulder Dia (MPN SP7-83). Key specifications — attr1132749: +0.062/-0.000 in; attr1110848: PCS; attr1132750: +0.0000/-0.0003 in; attr1132753: 0.03 in.
Brand: Pcs

The PCS Step Ejector Pin (Step Pin) is a general purpose stepped ejector pin made of tool steel. It has a 3/32 in nominal diameter, an 8 in overall length, and a 1/8 in shoulder diameter. The pin features a head radius of 0.03 in, with a head diameter tolerance of +0.062/-0.000 in and a body diameter tolerance of +0.0000/-0.0003 in.

View Product & Quote

Technical Specifications

Parameter	Value
Type	Tool Steel
Nom. Dia.	3/32 in
Overall Lg	8 in
Shoulder Dia	1/8 in
Manufacturer Part Number	SP7-83
