Omega 3G-OTH-178715 — Technical Specifications

Name: Omega 3G-OTH-178715 OMEGA Temperature and Humidity Transmitter: 4 to 20mA, Screw Terminals, -22°F to 167°F, HX93B (MPN HX93BC). Key specifications — Display Type: No Display; Humidity Accuracy: ±2.5% from 20 to 80% RH; ±3.5% from 5 to 20% and 80 to 95% RH; ±4% from 0 to 5% and 95 to 100% RH; 0 to 100%; Temperature Accuracy: ±1.25°C; Output: 4 to 20mA; Temperature Range: -22 °F to 167 °F.
Brand: Omega

The OMEGA HX93BC is an indoor wall-mount temperature and humidity transmitter with a 4 to 20mA output. It has no display and offers a temperature range of -22 °F to 167 °F with an accuracy of ±1.25°C. Humidity accuracy is ±2.5% from 20 to 80% RH, with extended ranges covering 0 to 100% RH.

View Product & Quote

Technical Specifications

Parameter	Value
Type	Screw Terminals, -22°F to 167°F, HX93B
Output	4 to 20mA
Display Type	No Display
Humidity Accuracy	±2.5% from 20 to 80% RH
Temperature Range	-22 °F to 167 °F
Temperature Accuracy	±1.25°C
Manufacturer Part Number	HX93BC
