Ntn 3G-OTH-104790 — Technical Specifications

Name: Ntn 3G-OTH-104790 NTN Pillow Block Bearing: 1 in Bore, SS, Set Screws, 1 27/64 in Shaft Ht, M12 Mounting Bolt Size (MPN SUCP205-16CC). Key specifications — Brand: NTN; Maximum Speed: 5,100 RPM; Mounting Bolt Size: M12; Standards: FDA; System of Measurement: Inch.
Brand: Ntn

The NTN SUCP205-16CC is a food-grade pillow block ball bearing with a 1-inch bore, designed for applications requiring FDA compliance. It features a stainless steel construction with set screws, a shaft height of 1 27/64 inches, and a maximum speed of 5,100 RPM. The bearing uses an M12 mounting bolt size and follows the inch system of measurement.

View Product & Quote

Technical Specifications

Parameter	Value
Type	SS, Set Screws, M12 Mounting Bolt Size
Brand	NTN
Shaft Ht	1 27/64 in
Standards	FDA
Maximum Speed	5,100 RPM
Mounting Bolt Size	M12
System Of Measurement	Inch
Manufacturer Part Number	SUCP205-16CC
