Ntn 3G-OTH-104826 — Technical Specifications
The NTN UCFL205-100D1 is a general purpose flange-mount ball bearing with a 1 in cylindrical bore, cast iron housing, and set screw locking. This 2-bolt flange unit has a 5 1/8 in length, 1 13/32 in width, and uses a 5/8 in mounting bolt. It is lubricated with NLGI #3 equivalent grease and is designed for inch-system applications.
Technical Specifications
| Parameter | Value |
|---|---|
| Lg | 5 1/8 in |
| Wd | 1 13/32 in |
| Bore | 1 in |
| Type | Cast Iron, Set Screws |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | NLGI #3 Equivalent |
| Mounting Bolt Size | 5/8 in |
| System Of Measurement | Inch |
| Manufacturer Part Number | UCFL205-100D1 |
