Ntn 3G-OTH-106774 — Technical Specifications

Name: Ntn 3G-OTH-106774 NTN 2 Bolt Flange Bearing: Radial Ball, 1 in Bore, SS, Set Screws, 4 29/32 in Lg, 1 13/32 in Wd (MPN SUCFL205-16). Key specifications — Bore Type: Cylindrical; Brand: NTN; Lubricant Material: FDA/USDA-H1 Solid Grease; Mounting Bolt Size: 5/8 in; System of Measurement: Inch; Included Bearing Cap: None.
Brand: Ntn

The NTN SUCFL205-16 is a food-grade flange-mount ball bearing with a 1-inch cylindrical bore, designed for industrial equipment. It features FDA/USDA-H1 solid grease lubrication and a 5/8-inch mounting bolt size, with a length of 4 29/32 inches and a width of 1 13/32 inches. This inch-system radial ball bearing includes set screws and no bearing cap.

View Product & Quote

Technical Specifications

Parameter	Value
Lg	4 29/32 in
Wd	1 13/32 in
Bore	1 in
Type	SS, Set Screws
Brand	NTN
Bore Type	Cylindrical
Lubricant Material	FDA/USDA-H1 Solid Grease
Mounting Bolt Size	5/8 in
Included Bearing Cap	None
System Of Measurement	Inch
Manufacturer Part Number	SUCFL205-16
