Ntn 3G-OTH-104958 — Technical Specifications

Name: Ntn 3G-OTH-104958 NTN 4 Bolt Flange Bearing: Radial Ball, 1 7/16 in Bore, SS, Set Screws, 4 19/32 in Lg, 1 3/4 in Wd (MPN SUCF207-23). Key specifications — Bore Type: Cylindrical; Brand: NTN; Lubricant Material: FDA/USDA-H1 Solid Grease; Mounting Bolt Size: 1/2 in; System of Measurement: Inch; Included Bearing Cap: None.
Brand: Ntn

The NTN 4 Bolt Flange Bearing is a food-grade flange-mount ball bearing with a 1 7/16 in cylindrical bore and stainless steel construction. It features set screws for shaft mounting, uses FDA/USDA-H1 solid grease lubrication, and has a 1/2 in mounting bolt size. The bearing measures 4 19/32 in length by 1 3/4 in width, with no included bearing cap.

View Product & Quote

Technical Specifications

Parameter	Value
Lg	4 19/32 in
Wd	1 3/4 in
Bore	1 7/16 in
Type	SS, Set Screws
Brand	NTN
Bore Type	Cylindrical
Lubricant Material	FDA/USDA-H1 Solid Grease
Mounting Bolt Size	1/2 in
Included Bearing Cap	None
System Of Measurement	Inch
Manufacturer Part Number	SUCF207-23
