Ntn 3G-OTH-102265 — Technical Specifications

Name: Ntn 3G-OTH-102265 NTN 4 Bolt Flange Bearing: Radial Ball, 1 1/4 in Bore, SS, Set Screws, 4 1/4 in Lg, 1 37/64 in Wd (MPN SUCF206-20). Key specifications — Bore Type: Cylindrical; Brand: NTN; Lubricant Material: FDA/USDA-H1 Solid Grease; Mounting Bolt Size: 7/16 in; System of Measurement: Inch; Included Bearing Cap: None.
Brand: Ntn

The NTN SUCF206-20 is a 4-bolt flange-mount ball bearing designed for food-grade applications, featuring a 1 1/4 in cylindrical bore and stainless steel construction with set screws. It uses FDA/USDA-H1 solid grease lubrication and has a mounting bolt size of 7/16 in, with dimensions of 4 1/4 in length and 1 37/64 in width. This inch-system bearing does not include a bearing cap.

View Product & Quote

Technical Specifications

Parameter	Value
Lg	4 1/4 in
Wd	1 37/64 in
Bore	1 1/4 in
Type	SS, Set Screws
Brand	NTN
Bore Type	Cylindrical
Lubricant Material	FDA/USDA-H1 Solid Grease
Mounting Bolt Size	7/16 in
Included Bearing Cap	None
System Of Measurement	Inch
Manufacturer Part Number	SUCF206-20
