Ntn 3G-OTH-112988 — Technical Specifications

Name: Ntn 3G-OTH-112988 NTN 4 Bolt Flange Bearing: Radial Ball, 3/4 in Bore, SS, Set Screws, 3 3/8 in Lg, 1 5/16 in Wd, 440C (MPN SUCF204-12). Key specifications — Bore Type: Cylindrical; Brand: NTN; Lubricant Material: FDA/USDA-H1 Solid Grease; Mounting Bolt Size: 7/16 in; System of Measurement: Inch; Included Bearing Cap: None.
Brand: Ntn

The NTN SUCF204-12 is a food-grade flange-mount ball bearing with a 3/4 in cylindrical bore, constructed from 440C stainless steel. It features set screws for shaft mounting, measures 3 3/8 in length by 1 5/16 in width, and uses FDA/USDA-H1 solid grease lubrication. This 4-bolt flange unit has a 7/16 in mounting bolt size and is designed for inch-system applications.

View Product & Quote

Technical Specifications

Parameter	Value
Lg	3 3/8 in
Wd	1 5/16 in
Bore	3/4 in
Type	SS, Set Screws, 440C
Brand	NTN
Bore Type	Cylindrical
Lubricant Material	FDA/USDA-H1 Solid Grease
Mounting Bolt Size	7/16 in
Included Bearing Cap	None
System Of Measurement	Inch
Manufacturer Part Number	SUCF204-12
