Ntn 3G-OTH-103158 — Technical Specifications
The NTN Pillow Block Bearing is a medium duty pillow block ball bearing with a 2 15/16 in bore, cast iron housing, and set screw locking. It has a maximum speed of 1,900 RPM, a mounting bolt size of 3/4 in, and a shaft height of 3 31/64 in. This inch-system bearing is identified by manufacturer part number UCPX-2.15/16M.
Technical Specifications
| Parameter | Value |
|---|---|
| Type | Cast Iron, Set Screws, 1,900 RPM |
| Brand | NTN |
| Shaft Ht | 3 31/64 in |
| Maximum Speed | 1,900 RPM |
| Mounting Bolt Size | 3/4 in |
| System Of Measurement | Inch |
| Manufacturer Part Number | UCPX-2.15/16M |
