Ntn 3G-OTH-101457 — Technical Specifications
The NTN 4 Bolt Flange Bearing is a general purpose flange-mount ball bearing with a 1 in cylindrical bore, cast iron housing, and set screw locking. It features an NLGI #3 equivalent lubricant, a 7/16 in mounting bolt size, and overall dimensions of 3 3/4 in length by 1 13/32 in width (MPN UCF205-100D1).
Technical Specifications
| Parameter | Value |
|---|---|
| Lg | 3 3/4 in |
| Wd | 1 13/32 in |
| Bore | 1 in |
| Type | Cast Iron, Set Screws |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | NLGI #3 Equivalent |
| Mounting Bolt Size | 7/16 in |
| System Of Measurement | Inch |
| Manufacturer Part Number | UCF205-100D1 |
