Ntn 3G-OTH-115658 — Technical Specifications
The NTN 4 Bolt Flange Bearing is a general purpose flange-mount ball bearing with a 5/8 in cylindrical bore and a cast iron housing. It features set screws for shaft locking and uses NLGI #3 equivalent lubricant. The unit has a 7/16 in mounting bolt size, a length of 3 3/8 in, and a height of 3 3/8 in, with the manufacturer part number UCF202-010D1.
Technical Specifications
| Parameter | Value |
|---|---|
| Ht | 3 3/8 in |
| Lg | 3 3/8 in |
| Bore | 5/8 in |
| Type | Cast Iron, Set Screws |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | NLGI #3 Equivalent |
| Mounting Bolt Size | 7/16 in |
| System Of Measurement | Inch |
| Manufacturer Part Number | UCF202-010D1 |
