Ntn 3G-OTH-109572 — Technical Specifications
The NTN SUCFB208 is a food-grade flange-mount ball bearing with a 40 mm cylindrical bore, stainless steel construction, and set screw locking. It features FDA/USDA-H1 solid grease lubrication, M12 mounting bolts, and dimensions of 100 mm length, 51.2 mm width, and 164 mm height. This metric 3-bolt flange bearing is designed without an included bearing cap.
Technical Specifications
| Parameter | Value |
|---|---|
| Ht | 164 mm |
| Lg | 100 mm |
| Wd | 51.2 mm |
| Bore | 40 mm |
| Type | SS, Set Screws |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | FDA/USDA-H1 Solid Grease |
| Mounting Bolt Size | M12 |
| Included Bearing Cap | None |
| System Of Measurement | Metric |
| Manufacturer Part Number | SUCFB208 |
