Ntn 3G-OTH-107041 — Technical Specifications
The NTN 3 Bolt Flange Bearing is a food-grade flange-mount radial ball bearing with a 1 7/16 in cylindrical bore, set screws, and an open cap. It features FDA/USDA-H1 solid grease lubrication and M12 mounting bolts, with dimensions of 3 17/32 in length and 1 3/4 in width (MPN SUCFB207-23C0FG1).
Technical Specifications
| Parameter | Value |
|---|---|
| Lg | 3 17/32 in |
| Wd | 1 3/4 in |
| Bore | 1 7/16 in |
| Type | SS, Set Screws |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | FDA/USDA-H1 Solid Grease |
| Mounting Bolt Size | M12 |
| Included Bearing Cap | Open Cap |
| System Of Measurement | Inch |
| Manufacturer Part Number | SUCFB207-23C0FG1 |
