Ntn 3G-OTH-111724 — Technical Specifications
The NTN 3 Bolt Flange Bearing is a food-grade flange-mount radial ball bearing with a 1 1/4 in cylindrical bore, stainless steel construction, and set screws for secure shaft mounting. It measures 3 17/32 in length by 1 3/4 in width, uses FDA/USDA-H1 solid grease lubrication, and has an M12 mounting bolt size. This inch-system bearing (MPN SUCFB207-20FG1) does not include a bearing cap.
Technical Specifications
| Parameter | Value |
|---|---|
| Lg | 3 17/32 in |
| Wd | 1 3/4 in |
| Bore | 1 1/4 in |
| Type | SS, Set Screws |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | FDA/USDA-H1 Solid Grease |
| Mounting Bolt Size | M12 |
| Included Bearing Cap | None |
| System Of Measurement | Inch |
| Manufacturer Part Number | SUCFB207-20FG1 |
