Ntn 3G-OTH-101728 — Technical Specifications
The NTN 3 Bolt Flange Bearing is a food-grade flange-mount radial ball bearing with a 1 1/4 in cylindrical bore, stainless steel construction, and set screws. It uses FDA/USDA-H1 solid grease lubrication, has an M8 mounting bolt size, and measures 3 1/8 in length by 1 37/64 in width. This inch-system bearing (MPN SUCFB206-20FG1) does not include a bearing cap.
Technical Specifications
| Parameter | Value |
|---|---|
| Lg | 3 1/8 in |
| Wd | 1 37/64 in |
| Bore | 1 1/4 in |
| Type | SS, Set Screws |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | FDA/USDA-H1 Solid Grease |
| Mounting Bolt Size | M8 |
| Included Bearing Cap | None |
| System Of Measurement | Inch |
| Manufacturer Part Number | SUCFB206-20FG1 |
