Ntn 3G-OTH-101822 — Technical Specifications
The NTN 3 Bolt Flange Bearing is a food-grade flange-mount radial ball bearing with a 1 1/4 in cylindrical bore, an open cap, and M8 mounting bolts. It is lubricated with FDA/USDA-H1 solid grease and secured with set screws. This inch-system bearing measures 3 1/8 in length and 1 37/64 in width (MPN SUCFB206-20C0FG1).
Technical Specifications
| Parameter | Value |
|---|---|
| Lg | 3 1/8 in |
| Wd | 1 37/64 in |
| Bore | 1 1/4 in |
| Type | SS, Set Screws |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | FDA/USDA-H1 Solid Grease |
| Mounting Bolt Size | M8 |
| Included Bearing Cap | Open Cap |
| System Of Measurement | Inch |
| Manufacturer Part Number | SUCFB206-20C0FG1 |
