Ntn 3G-OTH-100774 — Technical Specifications
The NTN 3 Bolt Flange Bearing is a food-grade flange-mount radial ball bearing with a 25 mm cylindrical bore, stainless steel construction, and set screws. It features an FDA/USDA-H1 solid grease lubricant, a closed cap, and M10 mounting bolts, with dimensions of 67 mm length, 35.8 mm width, and 119 mm height (MPN SUCFB205CCFG1).
Technical Specifications
| Parameter | Value |
|---|---|
| Ht | 119 mm |
| Lg | 67 mm |
| Wd | 35.8 mm |
| Bore | 25 mm |
| Type | SS, Set Screws |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | FDA/USDA-H1 Solid Grease |
| Mounting Bolt Size | M10 |
| Included Bearing Cap | Closed Cap |
| System Of Measurement | Metric |
| Manufacturer Part Number | SUCFB205CCFG1 |
