Ntn 3G-OTH-111693 — Technical Specifications

Name: Ntn 3G-OTH-111693 NTN 3 Bolt Flange Bearing: Radial Ball, 1 in Bore, SS, Set Screws, 2 5/8 in Lg, 1 13/32 in Wd, 440C (MPN SUCFB205-16C0). Key specifications — Bore Type: Cylindrical; Brand: NTN; Lubricant Material: FDA/USDA-H1 Solid Grease; Mounting Bolt Size: M8; System of Measurement: Inch; Included Bearing Cap: Open Cap.
Brand: Ntn

The NTN 3 Bolt Flange Bearing is a food-grade flange-mount radial ball bearing with a 1-inch cylindrical bore, an open cap, and set screws. It features FDA/USDA-H1 solid grease lubrication, M8 mounting bolts, and a 440C stainless steel construction, with dimensions of 2 5/8 inches in length and 1 13/32 inches in width.

View Product & Quote

Technical Specifications

Parameter	Value
Lg	2 5/8 in
Wd	1 13/32 in
Bore	1 in
Type	SS, Set Screws, 440C
Brand	NTN
Bore Type	Cylindrical
Lubricant Material	FDA/USDA-H1 Solid Grease
Mounting Bolt Size	M8
Included Bearing Cap	Open Cap
System Of Measurement	Inch
Manufacturer Part Number	SUCFB205-16C0
