Ntn 3G-OTH-111863 — Technical Specifications
The NTN 3 Bolt Flange Bearing is a food-grade flange-mount radial ball bearing with a 3/4 in cylindrical bore, designed for inch-system applications. It features FDA/USDA-H1 solid grease lubrication and a polymer housing with set screws, using a 3/8 in mounting bolt size. The bearing has a length of 2 1/2 in and a width of 1 53/64 in, with no included bearing cap.
Technical Specifications
| Parameter | Value |
|---|---|
| Lg | 2 1/2 in |
| Wd | 1 53/64 in |
| Bore | 3/4 in |
| Type | Polymer, Set Screws |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | FDA/USDA-H1 Solid Grease |
| Mounting Bolt Size | 3/8 in |
| Included Bearing Cap | None |
| System Of Measurement | Inch |
| Manufacturer Part Number | SUCFBL204-12 |
