Ntn 3G-OTH-106846 — Technical Specifications

Name: Ntn 3G-OTH-106846 NTN Insert Bearing: ZUC205-16, 1 in Bore, 2 3/64 in OD, 0.669 in Outer Ring Wd, Set Screws. Key specifications — System of Measurement: Inch; Manufacturer Part Number: ZUC205-16; Brand: NTN; Bearing Insert Type: Radial/Deep Groove Ball; Closure: Double Sealed; Bearing Industry Number: ZUC205-16.
Brand: Ntn

The NTN ZUC205-16 is a general purpose spherical insert bearing of the radial/deep groove ball type, featuring a double-sealed closure. It has a 1-inch bore, a 2 3/64-inch outer diameter, and a 0.669-inch outer ring width, with set screws for mounting. This inch-system bearing is identified by the industry number ZUC205-16.

View Product & Quote

Technical Specifications

Parameter	Value
OD	2 3/64 in
Bore	1 in
Type	Set Screws
Brand	NTN
Closure	Double Sealed
Outer Ring Wd	0.669 in
Bearing Insert Type	Radial/Deep Groove Ball
System Of Measurement	Inch
Bearing Industry Number	ZUC205-16
Manufacturer Part Number	ZUC205-16
