Ntn 3G-OTH-105002 — Technical Specifications
The NTN SUC211-35FG1 is a general purpose spherical insert bearing of the radial/deep groove ball type, featuring double-sealed closure and set screw locking. This inch-system bearing has a 2 3/16 in bore, a 3 59/64 in OD, and a 0.984 in outer ring width. It is identified by bearing industry number SUC211-35FG1.
Technical Specifications
| Parameter | Value |
|---|---|
| OD | 3 59/64 in |
| Bore | 2 3/16 in |
| Type | Set Screws |
| Brand | NTN |
| Closure | Double Sealed |
| Outer Ring Wd | 0.984 in |
| Bearing Insert Type | Radial/Deep Groove Ball |
| System Of Measurement | Inch |
| Bearing Industry Number | SUC211-35FG1 |
| Manufacturer Part Number | SUC211-35FG1 |
