Ntn 3G-OTH-104714 — Technical Specifications
The NTN 3 Bolt Flange Bearing is a food-grade flange-mount radial ball bearing with a 1 1/4 in cylindrical bore, an open cap, and a polymer housing. It features set screws for shaft mounting and uses FDA/USDA-H1 solid grease lubrication. The bearing has a 1/2 in mounting bolt size and is measured in inches (MPN SUCFBL207-20C0FG1).
Technical Specifications
| Parameter | Value |
|---|---|
| Lg | 3 47/64 in |
| Bore | 1 1/4 in |
| Type | Polymer, Set Screws, Open Cap |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | FDA/USDA-H1 Solid Grease |
| Mounting Bolt Size | 1/2 in |
| Included Bearing Cap | Open Cap |
| System Of Measurement | Inch |
| Manufacturer Part Number | SUCFBL207-20C0FG1 |
