Ntn 3G-OTH-104221 — Technical Specifications

Name: Ntn 3G-OTH-104221 NTN Pillow Block Bearing: 1 1/4 in Bore, Polymer, Set Screws, 1 55/64 in Shaft Ht, 212°F Max Temp (MPN SUCPPL207-20CCFG1). Key specifications — Brand: NTN; Mounting Bolt Size: 1/2 in; Standards: NSF H1; System of Measurement: Inch.
Brand: Ntn

The NTN SUCPPL207-20CCFG1 is a food-grade pillow block ball bearing with a 1 1/4 in bore, designed for industrial applications requiring NSF H1 compliance. This inch-system unit features a polymer housing, set screw locking, a 1 55/64 in shaft height, and a 212°F maximum temperature rating. It accommodates a 1/2 in mounting bolt size.

View Product & Quote

Technical Specifications

Parameter	Value
Type	Polymer, Set Screws
Brand	NTN
Max Temp	212°F
Shaft Ht	1 55/64 in
Standards	NSF H1
Mounting Bolt Size	1/2 in
System Of Measurement	Inch
Manufacturer Part Number	SUCPPL207-20CCFG1
