Ntn 3G-OTH-97335 — Technical Specifications
The NTN Ball Screw Support Bearing: 45X75 is a single, metric angular contact thrust bearing for ball screws, featuring a 45 mm bore and a 60° contact angle. This open bearing is ABEC 7 precision-rated with a thermoplastic cage, and is supplied as a single bearing (not matched). The bearing industry number is 45X75, with manufacturer part number BST45X75-1BP4.
Technical Specifications
| Parameter | Value |
|---|---|
| Row | 1 |
| Bore | 45 mm |
| Type | 60°, Open, ABEC 7, Thermoplastic Cage |
| Brand | NTN |
| Bearing Type | Single Bearing |
| Contact Bearing Type | Angular Contact |
| Matched Bearing Type | Not Matched/Single Bearing |
| System Of Measurement | Metric |
| Bearing Industry Number | 45X75 |
| Manufacturer Part Number | BST45X75-1BP4 |
