Ntn 3G-OTH-97177 — Technical Specifications
The NTN Ball Screw Support Bearing: 25X62 is a single angular contact thrust bearing for ball screws, featuring a 25 mm bore, 60° contact angle, open design, ABEC 7 precision, and a thermoplastic cage. This metric single bearing (MPN BST25X62-1BP4) is not matched, ensuring straightforward installation as a standalone component.
Technical Specifications
| Parameter | Value |
|---|---|
| Row | 1 |
| Bore | 25 mm |
| Type | 60°, Open, ABEC 7, Thermoplastic Cage |
| Brand | NTN |
| Bearing Type | Single Bearing |
| Contact Bearing Type | Angular Contact |
| Matched Bearing Type | Not Matched/Single Bearing |
| System Of Measurement | Metric |
| Bearing Industry Number | 25X62 |
| Manufacturer Part Number | BST25X62-1BP4 |
