Ntn 3G-OTH-97727 — Technical Specifications
The NTN 7205 is a duplex angular contact ball bearing, supplied as a matched pair for precision mounting. This open, single-row bearing features a 15° contact angle, a 25 mm bore, and meets ABEC 7 tolerance class. It is identified by the manufacturer part number 7205CG1DUJ74.
Technical Specifications
| Parameter | Value |
|---|---|
| Row | 1 |
| Bore | 25 mm |
| Type | Matched, Duplex, 15°, Open, ABEC 7, 2 PK |
| Brand | NTN |
| Bearing Type | Matched Bearing |
| Matched Mount Type | Matched Pair |
| Contact Bearing Type | Angular Contact |
| Matched Bearing Type | Duplex |
| System Of Measurement | Metric |
| Bearing Industry Number | 7205 |
| Manufacturer Part Number | 7205CG1DUJ74 |
