Ntn 3G-OTH-109613 — Technical Specifications
The NTN 2 Bolt Flange Bearing is a food-grade flange-mount radial ball bearing with a 1 3/8 in cylindrical bore, stainless steel construction, and set screws. It uses FDA/USDA-H1 solid grease lubrication, has a 1/2 in mounting bolt size, and measures 5 1/8 in length by 1 3/4 in width. This inch-system bearing (MPN SUCFL207-22) does not include a bearing cap.
Technical Specifications
| Parameter | Value |
|---|---|
| Lg | 5 1/8 in |
| Wd | 1 3/4 in |
| Bore | 1 3/8 in |
| Type | SS, Set Screws |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | FDA/USDA-H1 Solid Grease |
| Mounting Bolt Size | 1/2 in |
| Included Bearing Cap | None |
| System Of Measurement | Inch |
| Manufacturer Part Number | SUCFL207-22 |
