Multifan 3G-OTH-80131 — Technical Specifications
The MULTIFAN V4E35K3M71100 is a corrosion-resistant direct-drive panel exhaust fan with a 14-inch blade, 1/8 hp, and 2,150 cfm at 240V AC single phase. It features a fiberglass frame, cast construction, a permanent split capacitor motor with Class F insulation, and a totally enclosed air-over motor enclosure. The unit is assembled with intake guards and offers variable speed operation.
Technical Specifications
| Parameter | Value |
|---|---|
| AC | 240V |
| Type | 1/8 hp, 2,150 cfm, 1 ph, Totally Enclosed |
| Blade | 14 in |
| Brand | MULTIFAN |
| Assembled | Assembled |
| Guard Type | Intake |
| Motor Type | Permanent Split Capacitor |
| Frame Material | Fiberglass |
| Motor Enclosure | Totally Enclosed Air Over |
| Enclosure Design | Totally Enclosed Motor |
| Motor Insulation | Class F |
| Number Of Speeds | Variable |
| Nameplate Voltage | 240V AC |
| Guard Type Subheads | With Intake Guards |
| Method Of Construction | Cast |
| Manufacturer Part Number | V4E35K3M71100 |
