Metz Connect 3G-OTH-50547 — Technical Specifications

Name: Metz Connect 3G-OTH-50547 Sensor Cable: M12 Male Straight X M12 Male Straight, 5 Pins, Black, PUR, 1 m Cable Lg (MPN 142MDA22010). Key specifications — Cable Jacket Color: Black; End 1 Gender: Male; End 1 Mounting Orientation: Straight; End 2 Gender: Male; End 2 Mounting Orientation: Straight; End 2 Connection Type: M12; IP Rating: IPX7; Brand: METZ CONNECT.
Brand: Metz Connect

The METZ CONNECT Sensor Cable (SKU 802LH2, MPN 142MDA22010) is a double-ended cordset with a PUR jacket designed for twisting applications. It features M12 male straight connectors on both ends, 5 pins, a 1 m cable length, and a black PUR jacket. The cable has a wire size of 22 AWG/42 AWG and an IPX7 rating.

View Product & Quote

Technical Specifications

Parameter	Value
Brand	METZ CONNECT
IP Rating	IPX7
Wire Size	22 AWG/42 AWG
End 1 Gender	Male
End 2 Gender	Male
Cable Jacket Color	Black
Cable Jacket Material	PUR
End 1 Connection Type	M12
End 2 Connection Type	M12
Manufacturer Part Number	142MDA22010
End 1 Mounting Orientation	Straight
End 2 Mounting Orientation	Straight
