Johnson Controls 3G-OTH-175971 — Technical Specifications

Name: Johnson Controls 3G-OTH-175971 Pressure Transmitter: 0 psi to 100 psi, 0 to 10V DC, 3-Pin Packard Connector, 1/8 in Male NPT, IP67 (MPN P599VAPS101K). Key specifications — Accuracy: ±1.5%; Burst Pressure: 259 bar; Calibration Certificate Included: No NIST-Traceable Calibration Certificate Included; IP Rating: IP67; Housing Material: Stainless Steel; Output: 0 to 10V DC; Overpressure: 3x Range; Process Connection Type: NPT.
Brand: Johnson Controls

The JOHNSON CONTROLS Pressure Transmitter (SKU 53CW46, MPN P599VAPS101K) is a P599 Series pressure transmitter with a 0 psi to 100 psi range and a 0 to 10V DC output, featuring a 3-Pin Packard Connector and a 1/8 in Male NPT process connection. It offers ±1.5% accuracy, an IP67 rating, overpressure capability of 3x Range, and a burst pressure of 259 bar, with a stainless steel housing. This device does not include a NIST-traceable calibration certificate.

View Product & Quote

Technical Specifications

Parameter	Value
DC	0 to 10V
Type	IP67
Brand	JOHNSON CONTROLS
Output	0 to 10V DC
Series	P599
Accuracy	±1.5%
Male NPT	1/8 in
IP Rating	IP67
Overpressure	3x Range
Burst Pressure	259 bar
Housing Material	Stainless Steel
Packard Connector	3-Pin
Process Connection Type	NPT
Manufacturer Part Number	P599VAPS101K
Process Connection Gender	Male
Calibration Certificate Included	No NIST-Traceable Calibration Certificate Included
