Johnson Controls 3G-OTH-69783 — Technical Specifications
The JOHNSON CONTROLS Pneumatic Thermostat (SKU 38Y129, MPN T-3311-1) is a dual-temperature piston valve actuator thermostat with a remote-bulb sensor. It features a temperature control range of 60° to 150°F, 2-pipe high-volume air flow output, and thermostat action of Direct - 15 psig and Reverse - 20 psig. The unit mounts on the valve top with a 42-inch capillary length.
Technical Specifications
| Parameter | Value |
|---|---|
| Type | High Volume Pipes/Air Flow Output |
| Brand | JOHNSON CONTROLS |
| Pipes | 2 |
| Thermostat Action | Direct - 15 psig, Reverse - 20 psig |
| Manufacturer Part Number | T-3311-1 |
| Pneumatic Thermostat Type | Piston Valve Actuator with Remote-Bulb Sensor |
| Temperature Control Range | 60° to 150°F |
| Number Of Pipes/Air Flow Output | 2 Pipes, High Volume |
| Mounting Direction/Capillary Length | Valve Top, 42 in |
