Iptci Bearings 3G-OTH-103647 — Technical Specifications
The IPTCI BEARINGS Insert Bearing CL209-27 is a general purpose spherical insert bearing with a ball bearing insert type. It features a double sealed closure, a 1 11/16 inch bore, an 85 mm outer diameter, and a 0.866 inch outer ring width. This inch-system bearing is identified by the industry number CL209-27.
Technical Specifications
| Parameter | Value |
|---|---|
| OD | 85 mm |
| Bore | 1 11/16 in |
| Type | CL209-27 |
| Brand | IPTCI BEARINGS |
| Closure | Double Sealed |
| Outer Ring Wd | 0.866 in |
| Bearing Insert Type | Ball |
| System Of Measurement | Inch |
| Bearing Industry Number | CL209-27 |
| Manufacturer Part Number | CL209-27 |
