Ifm 3G-OTH-35878 — Technical Specifications
The IFM DTI420 is an IO-Link medium-range HF RFID device, specifically a read/write antenna operating at 13.56 MHz. It features a flush-mountable design with an M18 x 1 thread, a thermoplastic housing, and an IP 67 rating. The unit includes a power LED display and an M12 A-coded electrical connection, with protection class III.
Technical Specifications
| Parameter | Value |
|---|---|
| Type | IO-Link, Flush Mountable, IP 67/IP 69K, M18 x 1 x 50 mm |
| Brand | IFM |
| Display | Power LED |
| Material | Thermoplastic |
| IP Rating | IP 67 |
| Mounting Type | Flush Mountable |
| Frequency Type | High Frequency |
| Protection Class | III |
| Operating Frequency | 13.56 MHz |
| Mounting Thread Size | M18 x 1 |
| Electrical Connection | M12 A-Coding |
| Manufacturer Part Number | DTI420 |
