Honeywell 3G-OTH-66927 — Technical Specifications

Name: Honeywell 3G-OTH-66927 Actuator: Fire and Smoke Dampers, On/Off, Spring Return, 30 in-lb, 24V AC, Hardwired, NEMA 1 / IP40 (MPN MS8104F1010/U). Key specifications — Manufacturer Part Number: MS8104F1010/U; Shaft Rotation: CW/CCW; Stroke Degree: 95°; Input Voltage: 24V AC; Brand: HONEYWELL; For Use With Building Automation Systems: Building Automation System Compatible; Electrical Connection Type: Hardwired; Auxiliary Switch Included: No.
Brand: Honeywell

The Honeywell MS8104F1010/U is a fire and smoke damper actuator with a 24V AC input, 95° stroke, and CW/CCW shaft rotation. This on/off, spring return model delivers 30 in-lb torque and is hardwired with a NEMA 1 / IP40 enclosure. It is building automation system compatible and does not include an auxiliary switch.

View Product & Quote

Technical Specifications

Parameter	Value
AC	24V
Type	On/Off, Spring Return, 30 in-lb, Hardwired, NEMA 1 / IP40
Brand	HONEYWELL
Input Voltage	24V AC
Stroke Degree	95°
Shaft Rotation	CW/CCW
Manufacturer Part Number	MS8104F1010/U
Auxiliary Switch Included	No
Electrical Connection Type	Hardwired
For Use With Building Automation Systems	Building Automation System Compatible
