Honeywell 3G-OTH-67647 — Technical Specifications
The Honeywell MS4110A1200/U is a fail-safe actuator with spring return, designed for use with ball valves, butterfly valves, cage valves, dampers, and globe valves. It features a self-centering clamping shaft type, a 95° stroke degree, and CW/CCW shaft rotation, operating on an input voltage of 100 to 250V AC. This on/off actuator includes an auxiliary switch and screw terminals for electrical connection, and is compatible with building automation systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Type | On/Off, Spring Return |
| Brand | HONEYWELL |
| Shaft Type | Self-Centering Clamping |
| Input Voltage | 100 to 250V AC |
| Stroke Degree | 95° |
| Shaft Rotation | CW/CCW |
| Manufacturer Part Number | MS4110A1200/U |
| Auxiliary Switch Included | Yes |
| Electrical Connection Type | Screw Terminals |
| For Use With Building Automation Systems | Building Automation System Compatible |
