Honeywell 3G-OTH-67491 — Technical Specifications

Name: Honeywell 3G-OTH-67491 Actuator: Dampers, Floating Point, Non-Spring Return, 150 in-lb, 24V AC, Hardwired, NEMA 3 (MPN M6184D1035/U). Key specifications — Manufacturer Part Number: M6184D1035/U; Shaft Type: Double-Ended; Shaft Rotation: CW/CCW; Stroke Degree: 90 to 160°; Input Voltage: 24V AC; Brand: HONEYWELL; Electrical Connection Type: Hardwired; Auxiliary Switch Included: No.
Brand: Honeywell

The Honeywell M6184D1035/U is a non-fail-safe, non-spring return damper actuator with a double-ended shaft and a stroke degree of 90 to 160°. It operates on 24V AC input voltage, supports CW/CCW shaft rotation, and features a hardwired electrical connection with no auxiliary switch. This floating-point actuator delivers 150 in-lb of torque and is rated NEMA 3.

View Product & Quote

Technical Specifications

Parameter	Value
AC	24V
Type	Floating Point, Non-Spring Return, 150 in-lb, Hardwired, NEMA 3
Brand	HONEYWELL
Shaft Type	Double-Ended
Input Voltage	24V AC
Stroke Degree	90 to 160°
Shaft Rotation	CW/CCW
Manufacturer Part Number	M6184D1035/U
Auxiliary Switch Included	No
Electrical Connection Type	Hardwired
