Gems Sensors 3G-OTH-89478 — Technical Specifications
The GEMS SENSORS Air Flow Switch: Piston is an adjustable set point flow switch with a brass body and 1/2 in FNPT connection. It features a normally closed SPDT switch with a DC contact rating of 20 V and is suitable for hazardous locations rated Class I, Div 2, Groups A, B, C, D. The manufacturer part numbers are FS-10798 and 25365.
Technical Specifications
| Parameter | Value |
|---|---|
| FNPT | 1/2 in |
| Type | Brass, FNPT, SPDT, Adj |
| Brand | GEMS SENSORS |
| Set Point Type | Adjustable |
| Connection Size | 1/2 in |
| Switch Position | Normally Closed |
| Contact Rating (DC) | 20 V |
| Manufacturer Part Number | FS-10798, 25365 |
| Hazardous Location Specification | Class I, Div 2, Group A, B, C, D |
