Flowline 3G-OTH-90582 — Technical Specifications
The FLOWLINE Contact Ultrasonic Level Sensor is a guided wave radar sensor with a rod probe, designed for vertical mounting. It features an aluminum body, 316 stainless steel stem and probe, and offers +/-3 mm accuracy. The sensor operates on 10/30V DC with a 4 to 20mA output in a 3-wire configuration.
Technical Specifications
| Parameter | Value |
|---|---|
| NPT | 3/4 in |
| Type | Vertical, NPT |
| Brand | FLOWLINE |
| Accuracy | +/-3 mm |
| Probe Type | Rod |
| Body Material | Aluminum |
| Stem Material | 316 Stainless Steel |
| Probe Material | 316 Stainless Steel |
| Nameplate Voltage | 10/30V DC |
| Mounting Orientation | Vertical |
| Output Voltage Range | 4 to 20mA |
| Manufacturer Part Number | LG10-0003-01-036 |
| Output Wire Configuration | 3-Wire |
