Finish Thompson 3G-OTH-90271 — Technical Specifications
The FINISH THOMPSON Flow Meter is an inline paddlewheel flowmeter designed for chemicals and corrosive fluids. It features a PVDF body with 3/4 in FNPT connections, a Viton seal, and an LCD display measuring in liters with +/-0.5% accuracy. The unit operates on a maximum 3V DC supply and fits pipe sizes from 3/4 to 1 in with universal mounting orientation.
Technical Specifications
| Parameter | Value |
|---|---|
| FNPT | 3/4 in |
| Type | Chemicals/Corrosive Fluids, Paddlewheel, PVDF |
| Brand | FINISH THOMPSON |
| Accuracy | +/-0.5% |
| Display Type | LCD |
| Max. Voltage | 3V DC |
| For Pipe Size | 3/4 to 1 in |
| Seal Material | Viton |
| Unit Of Measure | Liters |
| Mounting Orientation | Universal |
| Manufacturer Part Number | 211013-5 |
