Eaton 3G-OTH-42707 — Technical Specifications

Name: Eaton 3G-OTH-42707 EATON NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 2, 45 A, 24V AC Coil (MPN AN19GN0T5E020). Key specifications — Brand: EATON; Auxiliary Contact Form: 1NO; Coil Voltage: 24V AC; Phase: Three; Operator: None; Operator Controls: None; Auxiliary Contacts Included: 1NO; Signaling Features: Pilot Light.
Brand: Eaton

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, designed for three-phase applications. This NEMA Size 2 unit features a 45 A rating, a 24V AC coil, and includes a 1NO auxiliary contact and a pilot light for signaling. It requires no thermal units, as they are not applicable to electronic overloads.

View Product & Quote

Technical Specifications

Parameter	Value
Type	NEMA Size 2, 45 A
Brand	EATON
Phase	Three
Poles	3
AC Coil	24V
Operator	None
Coil Voltage	24V AC
Operator Controls	None
Signaling Features	Pilot Light
Auxiliary Contact Form	1NO
Thermal Units Required	None (Not Applicable to Electronic Overloads)
Manufacturer Part Number	AN19GN0T5E020
Auxiliary Contacts Included	1NO
