Eaton 3G-OTH-24346 — Technical Specifications

Name: Eaton 3G-OTH-24346 EATON Circuit Breaker: 25 A Amps, 25 kA at 480V AC, Fixed, AB, Std Terminals Load Only, Std, 2 Poles (MPN PDG22F0025TFFL). Key specifications — Max. AIR Rating: 25 kA at 480V AC; Instantaneous Trip: Fixed; Phase Connection: AB; Terminal Connection: Standard Terminals Load Only; Frame Size: 225A/Frame 2.
Brand: Eaton

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT77, MPN PDG22F0025TFFL) is a 25 A, 2-pole unit with a 225A/Frame 2 frame size. It features a fixed instantaneous trip, a maximum AIR rating of 25 kA at 480V AC, and AB phase connection. Terminal connection is standard terminals load only.

View Product & Quote

Technical Specifications

Parameter	Value
Type	25 kA at 480V AC, Fixed, AB, Std Terminals Load Only, Std
Poles	2
Frame Size	225A/Frame 2
Max. AIR Rating	25 kA at 480V AC
Phase Connection	AB
Instantaneous Trip	Fixed
Terminal Connection	Standard Terminals Load Only
Manufacturer Part Number	PDG22F0025TFFL
