Eaton 3G-OTH-23693 — Technical Specifications

Name: Eaton 3G-OTH-23693 EATON Molded Case Circuit Breaker: 100 A Amps, 65kA at 600V AC, Fixed, ABC, Line/Load Lug, Std, HMCP (MPN HMCPE100R3C). Key specifications — Series: HMCP; Max. AIR Rating: 65kA at 600V AC; Instantaneous Trip: Fixed; Phase Connection: ABC; Terminal Connection: Line/Load Lug; Frame Size: 125A/EG.
Brand: Eaton

The EATON HMCPE100R3C is a molded case circuit breaker from the HMCP series, rated for 100 A and serving as a motor circuit protector. It features a 125A/EG frame size, a maximum AIR rating of 65kA at 600V AC, and a fixed instantaneous trip. The unit supports ABC phase connection and uses line/load lug terminals.

View Product & Quote

Technical Specifications

Parameter	Value
Type	65kA at 600V AC, Fixed, ABC, Line/Load Lug, Std, HMCP
Series	HMCP
Frame Size	125A/EG
Max. AIR Rating	65kA at 600V AC
Phase Connection	ABC
Instantaneous Trip	Fixed
Terminal Connection	Line/Load Lug
Manufacturer Part Number	HMCPE100R3C
