Eaton 3G-OTH-23891 — Technical Specifications

Name: Eaton 3G-OTH-23891 EATON Molded Case Circuit Breaker: 300 A Amps, 100kA at 240V AC, Fixed, ABC, Line/Load Lug, Std, HKD (MPN HKD3300). Key specifications — Series: HKD; Max. AIR Rating: 100kA at 240V AC; Instantaneous Trip: Fixed; Phase Connection: ABC; Terminal Connection: Line/Load Lug; Frame Size: 400A/K.
Brand: Eaton

The EATON HKD3300 is a K-Frame Molded Case Circuit Breaker from the HKD series, rated for 300 A amps with a 400A/K frame size. It features a maximum AIR rating of 100kA at 240V AC, fixed instantaneous trip, ABC phase connection, and line/load lug terminal connections.

View Product & Quote

Technical Specifications

Parameter	Value
Type	100kA at 240V AC, Fixed, ABC, Line/Load Lug, Std, HKD
Series	HKD
Frame Size	400A/K
Max. AIR Rating	100kA at 240V AC
Phase Connection	ABC
Instantaneous Trip	Fixed
Terminal Connection	Line/Load Lug
Manufacturer Part Number	HKD3300
