Eaton 3G-OTH-24073 — Technical Specifications

Name: Eaton 3G-OTH-24073 EATON Molded Case Circuit Breaker: 15 A Amps, 65kA at 480V AC, Fixed, ABC, Load Side Lug, Std (MPN PDG23M0015TFFL). Key specifications — Series: PD Series; Max. AIR Rating: 65kA at 480V AC; Instantaneous Trip: Fixed; Phase Connection: ABC; Terminal Connection: Load Side Lug; Frame Size: 2.
Brand: Eaton

The EATON Power Defense Molded Case Circuit Breaker (SKU 408PN3, MPN PDG23M0015TFFL) is a 15 A rated device from the PD Series with a Frame Size of 2. It features a fixed instantaneous trip, a maximum AIR rating of 65kA at 480V AC, and ABC phase connection. The breaker is equipped with load side lug terminal connections.

View Product & Quote

Technical Specifications

Parameter	Value
Type	65kA at 480V AC, Fixed, ABC, Load Side Lug, Std
Series	PD Series
Frame Size	2
Max. AIR Rating	65kA at 480V AC
Phase Connection	ABC
Instantaneous Trip	Fixed
Terminal Connection	Load Side Lug
Manufacturer Part Number	PDG23M0015TFFL
