Eaton 3G-OTH-20107 — Technical Specifications

Name: Eaton 3G-OTH-20107 EATON IEC Supplementary Protector: 15 A Amps, 48V DC, 15kA at 240/415V AC, Lug, FAZ, 277/480V AC, D (MPN FAZ-D15/1-SP). Key specifications — Brand: EATON; Terminal Connection: Lug; DC Voltage Rating: 48V DC; Max. AIR Rating: 15kA at 240/415V AC; Series: FAZ; AC Voltage Rating: 277/480V AC; Curve Type: D.
Brand: Eaton

The EATON FAZ-D15/1-SP is a D-curve, 1-pole UL1077 DIN rail-mount supplementary protector rated for 15 A. It supports AC voltages up to 277/480V AC and DC voltages up to 48V DC, with a maximum AIR rating of 15kA at 240/415V AC. This IEC supplementary protector features lug terminal connections and is part of the EATON FAZ series.

View Product & Quote

Technical Specifications

Parameter	Value
AC	277/480V
DC	48V
Type	15kA at 240/415V AC, Lug, FAZ, D
Brand	EATON
Series	FAZ
Curve Type	D
Max. AIR Rating	15kA at 240/415V AC
AC Voltage Rating	277/480V AC
DC Voltage Rating	48V DC
Terminal Connection	Lug
Manufacturer Part Number	FAZ-D15/1-SP
