Dwyer 3G-OTH-28352 — Technical Specifications
The Dwyer DPMP-502 is an LCD digital panel meter from the DPMP series, featuring a green high-contrast LCD display with a 1,999 display span and 0.45-inch digit height. It accepts DC current input with +/-0.1% accuracy, operates on 12-24 VDC, and includes screw clamp terminals. The meter is housed in a NEMA 4 rated enclosure.
Technical Specifications
| Parameter | Value |
|---|---|
| Type | - Max, 12 V DC – 24 V DC, 0.45 in Digit Ht - Max., LCD |
| Brand | DWYER |
| Series | DPMP |
| Accuracy | +/-0.1% |
| Input Type | DC Current |
| Product Type | LCD Digital Panel Meter |
| Display Features | High Contrast |
| NEMA Enclosure Rating | 4 |
| Manufacturer Part Number | DPMP-502 |
| Terminal Connection Type | Screw Clamp |
| Digital Display Screen Type | LCD |
| Digital Display Screen Color | Green |
