Dwyer 3G-OTH-180781 — Technical Specifications
The Dwyer RHPX-2SDA0-00 is a duct-mount temperature and humidity transmitter with a 0 to 10V DC output. It operates on 15 to 35V DC or 15 to 29V AC power, with a humidity accuracy of 2% and temperature accuracy of ±0.9°F at 77°F. The sensing element is a 0 to 5V DC solid state band gap, and the temperature range is -4 °F to 140 °F.
Technical Specifications
| Parameter | Value |
|---|---|
| Type | Screw Terminals, RHP |
| Brand | DWYER |
| Output | 0 to 10V DC |
| Power Source | 15 to 35V DC |
| Humidity Accuracy | 2% |
| Temperature Range | -4 °F to 140 °F |
| Sensing Element Type | 0 to 5V DC Solid State Band Gap |
| Temperature Accuracy | ±0.9°F at 77°F |
| DC Solid State Band Gap | 0 to 5V |
| Manufacturer Part Number | RHPX-2SDA0-00 |
