Dwyer 3G-OTH-174161 — Technical Specifications
The DWYER Differential Pressure Gauge: Back/Single-Side is a low operating pressure differential gauge from the Series 2000, model 2215. It features a 4-inch dial, a diaphragm sensor, and a die-cast aluminum housing with 1/8-inch NPT female connections, rated IP67. This gauge does not include a certificate of calibration.
Technical Specifications
| Parameter | Value |
|---|---|
| Dial | 4 in |
| Type | 2000, IP67, IP67 |
| Series | 2000 |
| NPT Female | 1/8 in |
| Sensor Type | Diaphragm |
| Housing Material | Die Cast Aluminum |
| Manufacturer Part Number | 2215 |
| Certificate Of Calibration | Not Included |
