Chainflex 3G-OTH-47011 — Technical Specifications

Name: Chainflex 3G-OTH-47011 CHAINFLEX Bus Cable: (2) 26 AWG (0.15), PUR, Order by the Foot, Single Pr Ethernet, Red (MPN CFBUS-PUR-042). Key specifications — Bus System: Single Pair Ethernet; Conductor Grouping: (2) 26 AWG; Minimum Bend Radius Factor - Fixed: 7 x OD; Minimum Bend Radius Factor - Flexible: 10 x OD; Shielding: Shielded; Brand: CHAINFLEX.
Brand: Chainflex

The CHAINFLEX Bus Cable: (2) 26 AWG (0.15) is a shielded continuous flexing bus drop cable designed for Single Pair Ethernet bus systems. It features (2) 26 AWG conductors, a PUR jacket, and minimum bend radius factors of 7 x OD for fixed installation and 10 x OD for flexible applications. This cable is available by the foot under MPN CFBUS-PUR-042.

View Product & Quote

Technical Specifications

Parameter	Value
Type	PUR, Order by the Foot, Single Pr Ethernet, Red
Brand	CHAINFLEX
Shielding	Shielded
Bus System	Single Pair Ethernet
Conductor Grouping	(2) 26 AWG
Manufacturer Part Number	CFBUS-PUR-042
Minimum Bend Radius Factor - Fixed	7 x OD
Minimum Bend Radius Factor - Flexible	10 x OD
