Chainflex 3G-OTH-46949 — Technical Specifications

Name: Chainflex 3G-OTH-46949 CHAINFLEX Bus Cable: (1) Pr 24 AWG (0.24)/(2) 20 AWG (0.5), TPR, Order by the Foot, USB, Red (MPN CFBUS-066). Key specifications — Bus System: USB; Conductor Grouping: (1) Pair 24 AWG/(2) 20 AWG; Minimum Bend Radius Factor - Fixed: 5 x OD; Minimum Bend Radius Factor - Flexible: 8 x OD; Shielding: Shielded; Brand: CHAINFLEX.
Brand: Chainflex

The CHAINFLEX Bus Cable (SKU 801MC3, MPN CFBUS-066) is a shielded, continuous-flexing USB bus drop cable with a conductor grouping of (1) pair 24 AWG and (2) 20 AWG. It features a minimum bend radius factor of 5 x OD for fixed installation and 8 x OD for flexible applications, and is available in red TPR jacket, sold by the foot.

View Product & Quote

Technical Specifications

Parameter	Value
Type	TPR, Order by the Foot, USB, Red
Brand	CHAINFLEX
Shielding	Shielded
Bus System	USB
Conductor Grouping	(1) Pair 24 AWG/(2) 20 AWG
Manufacturer Part Number	CFBUS-066
Minimum Bend Radius Factor - Fixed	5 x OD
Minimum Bend Radius Factor - Flexible	8 x OD
